MinisForum AI X1 Pro (AI 9 HX 370), barebone

The MINISFORUM AI X1-255 is a compact barebone mini PC powered by an AMD Ryzen 7 255 processor with integrated AMD Radeon 780M graphics. Two DDR5 SO-DIMM slots and two M.2 PCIe 4.0 slots allow users to configure the memory and storage according to their requirements. Dual USB4 ports, Wi-Fi 7, 2.5 Gigabit Ethernet and OCuLink support provide fast connectivity, multi-display operation and the option to connect an external graphics card.

Specifications:

Model: MINISFORUM AI X1-255
Type: Barebone mini PC
Processor: AMD Ryzen 7 255, 8 cores and 16 threads, up to 4.9 GHz
Graphics: Integrated AMD Radeon 780M
Memory: Not included
Memory slots: 2 × DDR5 SO-DIMM, 5600 MT/s
Maximum supported memory: 64 GB
SSD: Not included
Storage slots: 2 × M.2 2280 PCIe 4.0 ×4 NVMe
Maximum storage capacity: Up to 4 TB per slot and 8 TB in total
Operating system: Not included
Supported operating system: Windows 11
Wireless connectivity: Wi-Fi 7 and Bluetooth 5.4
Wired network: 2.5 GbE LAN
External graphics support: OCuLink via an M.2-to-OCuLink adapter board
Cooling: Phase-change thermal material, copper heat pipes and a large low-noise cooling fan
Speakers: 2 × built-in speakers
Microphones: 2 × built-in digital microphones
Dimensions: 128 × 126 × 52 mm
Weight: Approximately 0.6 kg

Video outputs:

1 × HDMI 2.1, up to 8K at 60 Hz or 4K at 120 Hz
1 × DisplayPort 2.0, up to 8K at 60 Hz or 4K at 120 Hz
2 × USB4, up to 8K at 60 Hz or 4K at 120 Hz

Other ports:

2 × USB4 Type-C, up to 40 Gbps
2 × USB 3.2 Gen 2 Type-A
1 × USB 2.0 Type-A
1 × RJ45 2.5 GbE
1 × OCuLink
1 × 3.5 mm combo audio jack
1 × Clear CMOS hole

Power adapter: 120 W, 19 V / 6.32 A
Internal reference: MSX1255B
EAN: 4897118834223

Package contents:

1 × MINISFORUM AI X1-255 barebone mini PC
1 × 120 W power adapter
1 × power cord
1 × M.2-to-OCuLink adapter board
1 × user manual

Note: Memory, SSD and operating system are not included.

Warranty: 24 months
