Eaton 5P 1150i 1150VA/770W

General Topology Line-Interactive High Frequency (Pure Sinewave, Booster + Fader) Configuration Tower Part Number 5P1150i Rating (VA/Watts) 1150/770 Dimensions (H x W x D, mm) 230 x 150 x 345 Weight (kg) 11.1 Warranty 3 years on electronics, 2 years on batteries Electrical Input Connection (1) IEC-320-C14 IEC C14 Input Voltage Without Using Batteries 160V-294V (adjustable to 150V-294V) Input frequency Range Without Using Batteries 47 to 70Hz (50 Hz system), 56.5 to 70Hz (60 Hz system), 40Hz in low-sensitivity mode Electrical Output Voltages 230 V (+6/-10 %) (Adjustable to 200V / 208V / 220V / 230V / 240V) Outlets (8) IEC-320-C13 IEC C13 Remotely controlled sockets 2 groups of 2 x IEC C13 (10 A) Output Frequency 50/60 Hz +/- 0.1 % (autosensing) Battery Battery Management ABM® or constant voltage charging method (user selectable), automatic battery test, deep discharge protection Communications Communication Ports 1 USB port + 1 RS232 serial port and relay contacts (USB and RS232 ports cannot be used simultaneously), 1 mini-terminal block for remote ON/OFF and Remote Power Off Communications Card Slots 1 slot for Network-MS card, ModBus-MS or Relay-MS cards Environmental & Standards Audible Noise < 40 dBA Operating Temperature 0 to 35°C Safety markings IEC/EN 62040-1, UL 1778 EMC Markings IEC/EN 62040-2, IEC/EN 62040-3 (performance) Approvals CE, CB report, TÜV
