Din Rail Mount Switch Power Supply Battery Back Up 24V DC 20 A Prikaži uvećano

Din Rail Mount Switch Power Supply Battery Back Up 24V DC 20 A

BVS480XDPDR

Novi proizvod

3 - 5 radnih dana

2 god.

Količina: 8 raspoloživa (kod dobavljača)

Cijena za gotovinu (uplatu na račun):

132,00 € s PDV-om

Cijena za kartice:

145,20 € s PDV-om

Okvirna cijena po ratama:
12 * 12,10 € s PDV-om
6 * 24,20 € s PDV-om
3 * 48,40 € s PDV-om

Dodaj u listu želja

  • Diners Club International
  • Discover
  • Dinacard
  • WSPay
  • Google Pay

Podaci

Width 4.00 cm
Height 12.90 cm
Depth 11.90 cm
Efficiency 95 %
Mounting Position Horizontal
Maximum Output Current 20 A
Battery type External battery system
Main Input Voltage 24 V DC
Main Output Voltage 24 V DC
Rated power in W 480 W
Product or component type Uninterruptible power supply (UPS)
Provided equipment User manual
Battery voltage 24 V
net. Weight 0.50 kg
Mounting mode DIN rail mount
Input voltage limits 21.6...28.8 V 24 V DC
Wave type DC
Product certifications CE, TÜV
Standards UL 60950-1, IEC 62368-1, CSA-C22.2 №. 62368-1-14, МЭК 61010-1
Ambient air temperature for operation -15…50 °C
Relative humidity 0…95 %
Operating altitude 0...3000 m
Ambient air temperature for storage -15…70 °C
Storage Relative Humidity 0…95 %
Storage altitude 0…3000 m
Acoustic level 40 dBA
Colour Gray
IP protection IP20
Connections - terminals 1 2 pins
Input protection type Integrated fuse (not interchangeable) Protected against short-circuit Against reverse polarity
Maximum Input Current per Phase 20 A
Number of input connectors 1 terminal block 2-wire
Output overload operation 60 seconds at 130% and 30 seconds at 145%

Više informacija

The Din Rail Mount Switch Power Supply Battery Back Up 24V DC 20A offers extraordinary power management for industrial and high-demand environments. This power supply is meticulously designed to ensure seamless and efficient performance, making it a vital component in automation systems, industrial controls, and critical infrastructure applications. The unit's din rail mount feature simplifies integration, providing a secure and organized setup in confined spaces. It excels in promoting system reliability with its robust 20A power output and an intelligent battery backup system, which activates immediately during power failures to prevent disruptions and safeguard valuable electronic equipment. Built to last, the power supply employs high-quality components that withstand harsh industrial conditions, guaranteeing durability and minimal maintenance needs. In addition to providing a stable and efficient power supply, its user-friendly design and easy installation process make it a preferred choice among engineers and technicians. Embrace continuity and efficiency with the 24V DC 20A Din Rail Mount Switch Power Supply and experience the assurance of uninterrupted operations.
