Besplatna dostava Switch 24-port GbE PoE.af/at(+) 410W 4xSFP L2 19i Prikaži uvećano

Switch 24-port GbE PoE.af/at(+) 410W 4xSFP L2 19i

EWS7928FP-FIT

Novi proizvod

3 - 5 radnih dana

2 god.

Količina: 1 raspoloživ (kod dobavljača)

Cijena za gotovinu (uplatu na račun):

532,13 € s PDV-om

Cijena za kartice:

585,34 € s PDV-om

Okvirna cijena po ratama:
12 * 48,78 € s PDV-om
6 * 97,56 € s PDV-om
3 * 195,11 € s PDV-om

Dodaj u listu želja

  • Diners Club International
  • Discover
  • Dinacard
  • WSPay
  • Google Pay

Podaci

Flash memory 32 MB
Power Source 100 ~ 240VAC, 50-60Hz
Port Standards 802.3 10Base-T Ethernet, 802.3u 100Base-TX Ethernet, 802.3ab 1000Base-T Ethernet, 802.3x Full-Duplex Flow Control
Network Ports 24xGE, 4xSFP
Switching Capacity 56 Gbps
SDRAM 256 MB
PoE Capable Ports 1-24
Total PoE Budget 410 W
System Indicators Power LED, Fault LED, PoE Max LED, LAN Mode LED, PoE Mode LED
Port Indicators Link/Activity/Speed (per Ethernet port), Link/Activity/Speed (per SFP slot)
Network Management EnGenius FITCloud, FITCON, Local Web GUI
MAC Address Table 8K
Jumbo frame size 9K
Multicast Group Max 256 groups
MLD Snooping MLD Snooping: v1
QoS Trust Mode Cos/802.1p, DSCP, CoS/802.1p-DSCP
Scheduling Mechanism Strict / WRR/ Strict + WRR
Bandwidth Control Port-based bandwidth control (Ingress/Egress)
Access Control List MAC Based ACL, IPv4/IPv6 Based ACL, ACL Binding, Time base ACL
Web Graphical User Interface (GUI) HTTP IPv4 / IPv6, HTTPS IPv4 / IPv6
SNMP v1, v2c, v3
RMON RMON 1,2,3,9
System Time Time Setting/Daylight saving
Common L2 Features 802.1d Spanning tree, Loopback Detection, Multicast Filitering, IGMP Multicast Forwarding, IGMP Snooping, MLD Multicast Forwarding, 802.1Q VLAN tagging, 802.3x flow control, 802.3ad Link Aggregation,
Multiple IP Interface 20 IPv6 address
IPv4 Static Route Max. 63 entries
IPv6 Static Route Max. 21 entries

Više informacija

Port standards
802.3 10Base-T Ethernet
802.3u 100Base-TX Ethernet
802.3ab 1000Base-T Ethernet
Full-duplex 802.3x flow control

Network Port – Gigabit Ethernet ports
24 GE ports

Network Port – SFP ports
4x SFP

Switching capacity
56 Gbps


256 MB SDRAM

Flash memory
32 MB

PoE-enabled ports
Ports 1-24

The total PoE budget
is 410 watts

Power supply
From 100 to 240 VAC, 50/60 Hz

System indicators
Power indicator
Fault LED
PoE Indicator Max.
LAN mode indicator
PoE mode indicator

Port indicators
Channel/Activity/Speed (for each Ethernet port)
Channel/Activity/speed (per SFP slot)

Network management
EnGenius FITCloud
FITCON
Local Web interface

MAC Address Table
8K

The frame size of the Jumbo
is 9K

Multicast group
Max. 256 groups

MLD Tracking
MLD Tracking: v1

QoS-the number of priority queues supported
Turn 8

QoS Trust Mode
Cos/802.1p
DSKP
CoS/802.1p-DSCP

The planning mechanism
Strict / WRR/ Strict + WRR

Bandwidth control
Port-based bandwidth management (inbound/outbound)

Port security
Max. 256 entries

MAC-based Access Control List (ACL)

IPv4/IPv6 based ACLs
Binding the ACL
to the ACL of the temporary database

Web-based Graphical User Interface (GUI)
HTTP IPv4/IPv6
HTTPS IPv4/IPv6

SSL certificate
Importing a certificate/key

SNMP
Support for SNMP v1/v2c/v3

RMON
RMON 1,2,3,9

System time
Setting the time/Summer time

General L2 functions
The 802.1d spanning tree
Feedback detection
Multicast filtering
Multicast
IGMP Forwarding IGMP Tracking
Multicast MLD Forwarding
Marking VLAN 802.1Q
802.3x Flow Control
802.3ad channel aggregation
IPv4 DHCP Relay
DHCP IPv4 Tracking
Checking the MAC address of the IPv4 DHCP Snooping source
Checking ARP packets (additional checks)
Voice VLAN
Port-based VLAN
Protocol-based VLAN
The CoS mapping
802. The 1X Radius Authentication Protocol
IPv4 Settings
IPv6 Settings
IEEE 802.3az Energy Efficient Ethernet (EEE)
SSH Server Command Line Interface (CLI)

Telnet server
TFTP client
Configuration update/Backup
Simple Network Time Protocol (SNTP)
System Log
The 802.1d spanning tree

Multiple IP interface
20 IPv6 address

ARP table
Max. 192 ARP entries

Static ARP
Static 192 ARP entries

Static IPv4 route
Max. 63 entries

Static IPv6 route
Max. 21 entries

Deployment options
Stand-alone (individually controlled)
FitXpress
Fitcontroller

Temperature range
Operating mode: 32°F to 122°F (0°C to 50°C)

Humidity (non-condensing)
Operation: 5% – 95%

Dimensions and weight of the device
Weight: 8.5 pounds. (3.9 kg)
Width: 17.32 inches (440 mm)
Depth: 10.23 inches (260 mm)
Height: 1.73 inches (44 mm)
