> Ostalo>Mrežna oprema>10/100/1000 switch >8 port>Cloud Managed Switch 8-port GbE PoE.af/at(+) 130W 2xGbE 2xSFP L2+ 13i
Cloud Managed Switch 8-port GbE PoE.af/at(+) 130W 2xGbE 2xSFP L2+ 13i Prikaži uvećano
Prije Dalje

Engenius Networks

Cloud Managed Switch 8-port GbE PoE.af/at(+) 130W 2xGbE 2xSFP L2+ 13i

ECS1112FP

Novi proizvod

Dobavljivo 1 kom kod dobavljača

Isporuka: 3 - 5 radnih dana

  • Jamstvo: 2 god.

Vaša prava iz zakonskog jamstva

Uplata na račun

309,38 €s PDV-omCijena na 10.9.2026.: 309,38 €

Plaćanje karticama

340,32 €

Cijena na 10.9.2026.: 340,32 €
12 × 28,36 € 6 × 56,72 € 3 × 113,44 €

Okvirna cijena po ratama karticama, s PDV-om

Isporuka: 3 - 5 radnih dana

Besplatno preuzimanje u Zagrebu: Mail Boxes Etc., Radnička cesta 20

Dodaj u listu želja

  • Diners Club International
  • Discover
  • Dinacard
  • WSPay
  • Google Pay
  • Visa
  • Mastercard
  • Maestro
  • Diners
  • Discover
  • DinaCard
  • KEKS Pay
  • PayPal
  • Google Pay
  • Bitcoin

Specifikacije

Flash memory
32 MB
Power Source
100 ~ 240VAC, 50-60Hz
Port Standards
802.3 10Base-T Ethernet, 802.3u 100Base-TX Ethernet, 802.3ab 1000Base-T Ethernet, 802.3x Full-Duplex Flow Control
Network Ports
10xGE, 2xSFP
Switching Capacity
24 Gbps
SDRAM
256 MB
PoE Capable Ports
1-8
Total PoE Budget
130 W
System Indicators
Power LED, Fault LED, PoE Max LED, LAN Mode LED, PoE Mode LED
Port Indicators
Link/Activity/Speed (per Ethernet port), Link/Activity/Speed (per SFP slot)
Network Management
EnGenius Cloud, Local Web GUI
MAC Address Table
8K
Jumbo frame size
10K
Multicast Group
Max 256 groups
MLD Snooping
MLD Snooping: v1
QoS Trust Mode
Cos/802.1p, DSCP, CoS/802.1p-DSCP
Scheduling Mechanism
Strict / WRR/ Strict + WRR
Bandwidth Control
Port-based bandwidth control (Ingress/Egress)
Port Security
Max. 256 Entries
Access Control List
MAC Based ACL, IPv4/IPv6 Based ACL, ACL Binding
Web Graphical User Interface (GUI)
HTTP IPv4 / IPv6, HTTPS IPv4 / IPv6
SNMP
v1, v2c, v3
RMON
RMON 1,2,3,9
System Time
Time Setting/Daylight saving
Common L2 Features
802.1D Spanning Tree, 802.1w Rapid Spanning Tree, 802.1S Rapid Spanning Tree, Loopback Detection, Multicast Filitering, IGMP Snooping, 802.1Q VLAN tagging, 802.3x flow control, 802.3ad Link Aggregation, IPv4 DHCP Relay, IPv4 DHCP Snooping, IPv4 DHCP Snooping Source MAC Address Check-up, ARP Packet Validation (additional validation checks), Voice VLAN, Port-based VLAN, CoS Mapping, 802. 1X Radius Authentication Protocol, IPv4 Settings/ IPv6 Settings, Command Line Interface (CLI), SSH Server, Telnet Server, TFTP Client, Configuration Upgrade/ Backup, Simple Network Time Protocol (SNTP), SYSLOG, Broadcast/Unknown Multicast/Unknown Unicast Storm Control
Multiple IP Interface
20 IPv6 address
IPv4 Static Route
Max. 63 entries
IPv6 Static Route
Max. 21 entries
Fiscalization 2.0 Article
G46.50.21

Opis

Port standards
802.3 10Base-T Ethernet
802.3u 100Base-TX Ethernet
802.3ab 1000Base-T Ethernet
Full-duplex 802.3x flow control

Network ports
10 ports 10/100/1000 Mbps + 2 SFP ports

Switching capacity
24 Gbps


256 MB SDRAM

Flash memory
32 MB

PoE+ enabled ports
1-8

Total PoE Budget
130 Watts

Power supply
100~240 VAC, 50-60 Hz

Physical interface

LED indicators
Power indicator
Fault LED
PoE Indicator Max.
LAN mode indicator
PoE mode indicator

Ports
Channel/Activity/Speed (for each Ethernet port)
Channel/Activity/speed (per SFP slot)

Multiple IP interface
20 IPv6 address

ARP table
Max. 192 ARP entries

Static ARP
Static 192 ARP entries

Static IPv4 route
Max. 63 entries

Static IPv6 route
Max. 21 entries

MAC Address Table
8K

Jumbo frame
9K

Multicast group
Max. 256 groups

MLD Tracking
MLD Tracking: v1

QoS — the number of priority queues supported
Turn 8

Trust mode
Cos/802.1p
DSKP
CoS/802.1p-DSCP

The planning mechanism
Strict / WRR/ Strict + WRR

Bandwidth control
Port-based bandwidth management (inbound/outbound)

Port security
Max. 256 entries

MAC-based Access Control List (ACL)

IPv4/IPv6 based ACLs
Binding the ACL
to the ACL of the temporary database

Web-based Graphical User Interface (GUI)
HTTP IPv4/IPv6
HTTPS IPv4/IPv6

SSL certificate
Importing a certificate/key

SNMP
Support for SNMP v1/v2c/v3

RMON
RMON 1,2,3,9

System time
Setting the time/Summer time

General L2 functions
The 802.1d spanning tree
Feedback detection
Multicast filtering
Multicast
IGMP Forwarding IGMP Tracking
Multicast MLD Forwarding
Marking VLAN 802.1Q
802.3x Flow Control
802.3ad channel aggregation
IPv4 DHCP Relay
DHCP IPv4 Tracking
Checking the MAC address of the IPv4 source DHCP Snooping
ARP Inspection
Checking ARP packets (additional checks)
Voice VLAN
Port-based VLAN
Protocol-based VLAN
The CoS mapping
802. The 1X Radius Authentication Protocol
IPv4 Settings
IPv6 Settings
IEEE 802.3az Energy Efficient Ethernet (EEE)
SSH Server Command Line Interface (CLI)

Telnet server
TFTP client
Updating/backing up the configuration
Simple Network Time Protocol (SNTP)
System Log

Temperature range
Operating mode: 32°F to 122°F (0°C to 50°C)

Humidity (non-condensing)
Operation: 5% - 95%

package contents
1 Gigabit switch with cloud management
1x Quick Installation Guide
1x Power Cord
1 RJ45 Console Cable
1x Rack Mount Kit

The ECS1112FP device
Weight: 4.4 pounds. (1.9 kg)
Width: 13 inches (330.20mm)
Length: 9 inches (228.60 mm)
Height: 1.73 inches (43.94 mm)
