> >>Mini PC Palit Pandora NVIDIA Jetson Orin™ NX Super /Cortex-A78AE/16GB/SSD128GB/Ampere/Linux
Novo Besplatna dostava Komputer Mini PC Palit Pandora NVIDIA Jetson Orin™ NX Super /Cortex-A78AE/16GB/SSD128GB/Ampere/Linux Prikaži uvećano
Prije Dalje

Mini PC Palit Pandora NVIDIA Jetson Orin™ NX Super /Cortex-A78AE/16GB/SSD128GB/Ampere/Linux

A002FV1P1

Novi proizvod

(više informacija)

Vaša prava iz zakonskog jamstva

  • NVIDIA Jetson Orin™ NX Super Ready
  • Compact Size : 145mm × 123mm × 66mm
  • 4×M.2, 8 Lanes MIPI CSI-2, and I2C / UART / GPIO / CAN Bus
  • 2×USB3.2 Gen2, 2 × USB2.0, 1 x Nano SIM Card Slot
  • 1×HDMI2.0

Više detalja

Količina: 1 raspoloživ (kod dobavljača)

Cijena za gotovinu (uplatu na račun):

2 039,70 € s PDV-omCijena na 14.10.2026.: 2 039,70 €

Cijena za kartice:

2 243,67 € s PDV-omCijena na 14.10.2026.: 2 243,67 €

Okvirna cijena po ratama:
12 * 186,97 € s PDV-om
6 * 373,95 € s PDV-om
3 * 747,89 € s PDV-om

Dodaj u listu želja

  • Diners Club International
  • Discover
  • Dinacard
  • WSPay
  • Google Pay

Više informacija

Specifications
SYSTEM
SOM Module NVIDIA® Jetson Orin™ NX 8GB Super NVIDIA® Jetson Orin™ NX 16GB Super
CPU
  • 6-Core Arm® Cortex®-A78AE v8.2 64-Bit CPU
  • 1.5MB L2 + 4MB L3
  • 8-Core Arm® Cortex®-A78AE v8.2 64-Bit CPU
  • 2MB L2 + 4MB L3
GPU 1024-Core NVIDIA Ampere Architecture GPU with 32 Tensor Cores
AI Performance 117 / 58 TOPS (Sparse / Dense) 157 / 78 TOPS (Sparse / Dense)
System Memory
  • 8GB 128-bit LPDDR5
  • total 102.4 GB/s bandwidth
  • 16GB 128-bit LPDDR5
  • total 102.4 GB/s bandwidth
Part Number A001FV1P1 A002FV1P1
INTERFACE
Storage Supports External NVMe
Display Interface 1×HDMI2.0
Ethernet 2×RJ45 for 10/100/1000Mbps Ethernet DHCP Client
USB
  • 2×USB3.2 Gen2 ( Type-A )
  • 1×USB3.2 Gen2 ( Type-C ) ( OTG )
  • 2×USB2.0 ( Type-A )
Expansion Slot
  • 1×M.2 2280 M Key PCIe Gen4×2 Slot ( with Pre-Installed 128GB SSD )
  • 1×M.2 2280/3080 M Key PCIe Gen4×4 Slot, Support SSD or Video Capture Cards
  • 1×M.2 2230 E Key PCIe Gen4×1+USB2.0 Slot, Support WiFi Module.
  • 1×M.2 3042/3052 B Key USB3.2 Gen1 Slot, Support 5G/4G Wireless Module.
MIPI
  • 8-Lane MIPI CSI-2
  • ( D-PHY 2.1, Support MIPI Camera, Capture Card )
Audio
  • 1×Line In ( 3.5mm Phone Jack )
  • 1×Line Out ( 3.5mm Phone Jack )
Peripheral Communication
  • 40 Pin Header
  • 1×I2S
  • 2×I2C
  • 2×SPI
  • 1×UART
  • 3×GPIO
  • 14 Pin Header
  • 1×CAN Bus
  • 1×UART with CTS/RTS
  • 1×UART for Debug
  • 1×Nano SIM Card Slot
Misc. Features
  • Firmware Upgradable
VIDEO FEATURE
Video Encode
  • AV1 ( UHP ) - 1×4K60 | 3×4K30 | 6×1080p60 | 12×1080p30
  • H.265 ( UHP )- 1×4K60 | 3×4K30 | 6×1080p60 | 12×1080p30
  • H.264 ( UHP ) - 1×4K60 | 2×4K30 | 5×1080p60 | 11×1080p30
Video Decode
  • AV1 ( Main Profile ) - 1×8K30 | 2×4K60 | 4×4K30 | 10×1080p60 | 20×1080p30
  • H.265 ( Main, Main10 ) - 1×8K30 | 2×4K60 | 4×4K30 | 9×1080p60 | 18×1080p30
  • H.264 ( Baseline, Main, High ) - 1×4K60 | 2×4K30 | 5×1080p60 | 11×1080p30
  • VP9 ( Profile 0, Profile 2 ) - 1×4K60 | 3×4K30 | 7×1080p60 | 15×1080p30
DEVELOPMENT ENVIRONMENT
JetPack 6.2 or Higher
ENVIRONMENT
Power Supply DC input : 12~36V
Operating Temperature Standard Version: 0~60°C with Airflow
Storage Temperature -20~80°C
MECHANICAL
Dimension of Main Board 115mm × 115mm
Dimension of System 145mm × 123mm × 66mm
Weight 470g
