- Jamstvo: 3 god.
Vaša prava iz zakonskog jamstva
- Odstrani ovaj proizvod iz najdražih proizvoda
- Dodaj ovaj proizvod u najdraže proizvode
- Ispis
Specifikacije
- Width
- 43.20 cm
- Height
- 17.40 cm
- Depth
- 71.94 cm
- Battery Recharge Time
- 1.5 h
- Battery Life
- 3...5 year(s)
- Battery type
- Lead-acid battery
- Type of execution
- Rackmount
- Main Input Voltage
- 230 V
- Main Output Voltage
- 230 V
- Rated power in W
- 6000 W
- Rated power in VA
- 6 kVA
- Product or component type
- Uninterruptible power supply (UPS)
- Output Connection Type
- 6 IEC 60320 C13, 2 IEC Jumpers, 4 IEC 60320 C19
- Provided equipment
- USB cable
- Battery voltage
- 192 V
- Redundant
- No
- net. Weight
- 60.00 kg
- Mounting preference
- Lower
- Mounting mode
- Rack-mounted
- USB compatible
- Yes
- Network frequency
- 40...70 Hz auto-sensing
- Input voltage limits
- 100...275 V adjustable (for half load)
- Maximum configurable power in VA
- 6000 VA
- Maximum configurable power in W
- 6000 W
- Output frequency
- 50/60 Hz +/- 3 Hz sync to mains
- UPS type
- Double conversion online
- Wave type
- Sine wave
- Product certifications
- CE, EAC, IRAM, RCM, VDE
- Standards
- EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018
- Ambient air temperature for operation
- 0..40 °C
- Relative humidity
- 0…95 %
- Operating altitude
- 0...10000 ft
- Ambient air temperature for storage
- -15…45 °C
- Storage Relative Humidity
- 0…95 %
- Storage altitude
- 0.0000000000…15240.0000000000 m
- Acoustic level
- 55 dBA
- Alarm
- Audible and visible alarms : prioritized by severity
- Surge energy rate
- 480 J
- Battery charger power
- 597 W nominal
- Mounting location
- Front
- Number of power module free slots
- 0
- Number of battery filled slots
- 0
- Number of battery free slots
- 0
- Fiscalization 2.0 Article
- G46.50.22
- Number of power module filled slots
- 0
Opis
Main Features:
- The main input voltage is 230 B
- Other Input voltage 220 B; 240 B
- The main output voltage is 230 V
- Other Output voltage 220 V; 240 V
- Rated power [W] 6000 W
- Rated power of 6000 VA
- Output connection type 6 IEC 60320 C13; 2 IEC Jumpers; 4 IEC 60320 C19
- Type of output connection All-in-one three-wire (H N + E) 1
- Number of Unit 4U
- Battery type Lead acid battery
Common:
- Product subcategory web - High density
- The number of slots unoccupied by power modules is 0
- Number of slots occupied by power modules - 0
- Spare - No
Physical parameters:
- The Color is Black
- Height 17.4 cm
- Width 43.2 cm
- Depth 71.94 cm
- Net weight 60 kg
- Installation location - Front
- Type of fastener - Bottom
- Mounting design - Rack-mounted
- Two-support mount - 0
- USB-compatible - Yes
- Mounting position - Horizontal
Entrance:
- Network frequency 40-70 Hz auto detection
- Number of input connections 1 All-in-one three-wire (1P + N + E)
- Input voltage limits of 100...275 V adjustable (for half load)
Output:
- Maximum set power (W) - 6000 W
- Harmonic distortion - Less than 2%
- Output frequency - 50/60 Hz +/- 3 Hz synchronized with the power grid
- Cross factor - 3:1
- UPS type - Dual conversion topology
- Type of voltage form - Sinusoidal signal
- Bypass type - Internal bypass (automatic and manual)
- Maximum set power (VA) - 6000 VA
Accordance:
- CE; EAC; IRAM; RCM; VDE certificates
- Marking - CE mark
- Standards - EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018
Environmental parameters:
- Ambient operating temperature - 0...40 °C
- Relative humidity - 0...95% without condensation
- Altitude above sea level - 0...10000 ft
- Ambient temperature during storage -15...45 °C
- Relative humidity of storage - 0...95% without condensation
- Storage height - 0.00...15240.00 m
- Acoustic level - 55 dBA
- Heat transfer - 1300 ‰
- Degree of protection IP - IP20
Batteries and battery life:
- Pre-installed batteries - 0
- Typical recharge time is 1.5 h
- Number of RBC™ cartridges - 1
- Battery voltage - 192 V
- Charger power (W) - 597 W rated
- Battery capacity in volt-ampere hours - 902 vach working time
- Battery life - 3...5 year(s)
- Spare battery - APCRBC140
- Battery options - SRT192RMBP 1 2706 VACH
SRT192RMBP 2 4510 VACH
SRT192RMBP 3 6314 VACH
SRT192RMBP 4 8118 VACH
SRT192RMBP 5 9922 VACH
SRT192RMBP 6 11726 VACH
SRT192RMBP 8 15334 VACH
SRT192RMBP 10 18942 VACH
- The possibility of increasing the time of autonomy - 1
Communication tools and admin tools
- Free slots - 1
- Alarm - Audible and visible alarms : prioritized by severity
- Emergency Power Off (EPO) - Yes
Protection against voltage surges and filtration:
- Rating according to the level of absorbed energy of the vsp - 480 J
- The main input voltage is 230 B
- Other Input voltage 220 B; 240 B
- The main output voltage is 230 V
- Other Output voltage 220 V; 240 V
- Rated power [W] 6000 W
- Rated power of 6000 VA
- Output connection type 6 IEC 60320 C13; 2 IEC Jumpers; 4 IEC 60320 C19
- Type of output connection All-in-one three-wire (H N + E) 1
- Number of Unit 4U
- Battery type Lead acid battery
Common:
- Product subcategory web - High density
- The number of slots unoccupied by power modules is 0
- Number of slots occupied by power modules - 0
- Spare - No
Physical parameters:
- The Color is Black
- Height 17.4 cm
- Width 43.2 cm
- Depth 71.94 cm
- Net weight 60 kg
- Installation location - Front
- Type of fastener - Bottom
- Mounting design - Rack-mounted
- Two-support mount - 0
- USB-compatible - Yes
- Mounting position - Horizontal
Entrance:
- Network frequency 40-70 Hz auto detection
- Number of input connections 1 All-in-one three-wire (1P + N + E)
- Input voltage limits of 100...275 V adjustable (for half load)
Output:
- Maximum set power (W) - 6000 W
- Harmonic distortion - Less than 2%
- Output frequency - 50/60 Hz +/- 3 Hz synchronized with the power grid
- Cross factor - 3:1
- UPS type - Dual conversion topology
- Type of voltage form - Sinusoidal signal
- Bypass type - Internal bypass (automatic and manual)
- Maximum set power (VA) - 6000 VA
Accordance:
- CE; EAC; IRAM; RCM; VDE certificates
- Marking - CE mark
- Standards - EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018
Environmental parameters:
- Ambient operating temperature - 0...40 °C
- Relative humidity - 0...95% without condensation
- Altitude above sea level - 0...10000 ft
- Ambient temperature during storage -15...45 °C
- Relative humidity of storage - 0...95% without condensation
- Storage height - 0.00...15240.00 m
- Acoustic level - 55 dBA
- Heat transfer - 1300 ‰
- Degree of protection IP - IP20
Batteries and battery life:
- Pre-installed batteries - 0
- Typical recharge time is 1.5 h
- Number of RBC™ cartridges - 1
- Battery voltage - 192 V
- Charger power (W) - 597 W rated
- Battery capacity in volt-ampere hours - 902 vach working time
- Battery life - 3...5 year(s)
- Spare battery - APCRBC140
- Battery options - SRT192RMBP 1 2706 VACH
SRT192RMBP 2 4510 VACH
SRT192RMBP 3 6314 VACH
SRT192RMBP 4 8118 VACH
SRT192RMBP 5 9922 VACH
SRT192RMBP 6 11726 VACH
SRT192RMBP 8 15334 VACH
SRT192RMBP 10 18942 VACH
- The possibility of increasing the time of autonomy - 1
Communication tools and admin tools
- Free slots - 1
- Alarm - Audible and visible alarms : prioritized by severity
- Emergency Power Off (EPO) - Yes
Protection against voltage surges and filtration:
- Rating according to the level of absorbed energy of the vsp - 480 J
