- Jamstvo: 3 god.
Vaša prava iz zakonskog jamstva
- Odstrani ovaj proizvod iz najdražih proizvoda
- Dodaj ovaj proizvod u najdraže proizvode
- Ispis
Specifikacije
- Width
- 43.20 cm
- Height
- 13.00 cm
- Depth
- 71.94 cm
- Battery Recharge Time
- 1.5 h
- Battery Life
- 3...5 year(s)
- Battery type
- Lead-acid battery
- Type of execution
- Rackmount
- Main Input Voltage
- 230 V
- Main Output Voltage
- 230 V
- Rated power in W
- 4.5 kW
- Rated power in VA
- 5 kVA
- Product or component type
- Uninterruptible power supply (UPS)
- Output Connection Type
- 6 IEC 60320 C13, 2 IEC Jumpers, 4 IEC 60320 C19
- Provided equipment
- User manual
- Battery voltage
- 192 V
- Redundant
- No
- net. Weight
- 54.43 kg
- Mounting preference
- No preference
- Mounting mode
- Rack-mounted
- USB compatible
- Yes
- Network frequency
- 40...70 Hz auto-sensing
- Input voltage limits
- 100...275 V adjustable (for half load)
- Maximum configurable power in VA
- 5000 VA
- Maximum configurable power in W
- 4500 W
- Output frequency
- 50/60 Hz +/- 3 Hz sync to mains
- UPS type
- Double conversion online
- Wave type
- Sine wave
- Product certifications
- CE, EAC, IRAM, RCM, VDE
- Standards
- EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018
- Ambient air temperature for operation
- 0..40 °C
- Relative humidity
- 0…95 %
- Operating altitude
- 0...10000 ft
- Ambient air temperature for storage
- -15…45 °C
- Storage Relative Humidity
- 0…95 %
- Storage altitude
- 0.0000000000…15240.0000000000 m
- Acoustic level
- 55 dBA
- Alarm
- Audible and visible alarms : prioritized by severity
- Surge energy rate
- 480 J
- Battery charger power
- 560 W nominal
- Mounting location
- Front
- Number of battery replacement quantity
- 1
- Number of power module free slots
- 1
- Number of battery filled slots
- 0
- Number of battery free slots
- 0
- Fiscalization 2.0 Article
- G46.50.22
- Number of power module filled slots
- 0
Opis
Main Features:
- The main input voltage is 230 B
- Other Input voltage 220 B; 240 B
- The main output voltage is 230 V
- Other Output voltage 220 V; 240 V
- Rated power [W] 4500 W
- Rated power 5000 VA
- Output connection type 6 IEC 60320 C13; 2 IEC Jumpers; 4 IEC 60320 C19
- Number of Unit 3U
- Battery type Lead acid battery
Common:
- Web High density product subcategory
- The number of slots unoccupied by power modules is 0
- Number of slots occupied by power modules - 0
- Spare - No
Physical parameters:
- The Color is Black
- Height 13 cm
- Width 43.2 cm
- Depth 71.94 cm
- Net weight 54.43 kg
- Installation location - Front
- Type of fastener - No preference
- Mounting design - Rack-mounted
- Two-support mount - 0
- USB-compatible - Yes
- Mounting position - Horizontal
Entrance:
- Network frequency - 40-70 Hz auto detection
- Number of input connections - 1 All-in-one three-wire (1P + N + E)
- Input voltage limits - 100...275 V adjustable (for half load)
Output:
- Maximum set power (W) - 4500 W
- Harmonic distortion - Less than 2%
- Output frequency - 50/60 Hz +/- 3 Hz synchronized with the power grid
- Cross factor - 3:1
- UPS type - Dual conversion topology
- Type of voltage form - Sinusoidal signal
- Bypass type - Internal bypass (automatic and manual)
- Maximum set power (VA) - 5000 VA
Accordance:
- Certificates - CE; EAC; IRAM; RCM; VDE
- Marking - CE mark
- Standards - EN/IEC 62040-1:2019/A11:2021; EN/IEC 62040-2:2006/AC:2006; EN/IEC 62040-2:2018
Environmental parameters:
- Ambient operating temperature - 0...40 °C
- Relative humidity - 0...95% without condensation
- Altitude above sea level - 0...10000 ft
- Ambient temperature during storage -15...45 °C
- Relative humidity of storage - 0...95% without condensation
- Storage height 0.00...15240.00 m
- Acoustic level 55 dBA
- Heat dissipation - 931
% - Degree of protection IP - IP20
Batteries and battery life:
- Pre-installed batteries - 0
- Typical recharge time of 1.5 h
- Number of RBC™ cartridges 1
- Battery voltage 192 V
- Charger power (W) - 560 W rated
- Battery capacity in volt-ampere hours - 845 Vach working time
- Battery life 3...5 year(s)
- Spare battery APCRBC140; SR13KXIET; SR16KXIET
- Battery options - SRT192RMBP 1 2535 VACH
SRT192RMBP 2 4225 VACH
SRT192RMBP 3 5915 VACH
SRT192RMBP 4 7605 VACH
SRT192RMBP 5 9295 VACH
SRT192RMBP 6 10985 VACH
SRT192RMBP 8 14365 VACH
SRT192RMBP 10 17745 VACH
- The possibility of increasing the time of autonomy - 1
Communication tools and admin tools:
- Free slots - 1
- Pre-installed SmartSlot&tra boards - Network management card 3 with environmental monitoring
- Alarm - Audible and visible alarms : prioritized by severity
- Emergency Power Off (EPO) - Yes
Surge protection and filtration:
- Rating according to the level of absorbed energy of the vsp - 480 J
- The main input voltage is 230 B
- Other Input voltage 220 B; 240 B
- The main output voltage is 230 V
- Other Output voltage 220 V; 240 V
- Rated power [W] 4500 W
- Rated power 5000 VA
- Output connection type 6 IEC 60320 C13; 2 IEC Jumpers; 4 IEC 60320 C19
- Number of Unit 3U
- Battery type Lead acid battery
Common:
- Web High density product subcategory
- The number of slots unoccupied by power modules is 0
- Number of slots occupied by power modules - 0
- Spare - No
Physical parameters:
- The Color is Black
- Height 13 cm
- Width 43.2 cm
- Depth 71.94 cm
- Net weight 54.43 kg
- Installation location - Front
- Type of fastener - No preference
- Mounting design - Rack-mounted
- Two-support mount - 0
- USB-compatible - Yes
- Mounting position - Horizontal
Entrance:
- Network frequency - 40-70 Hz auto detection
- Number of input connections - 1 All-in-one three-wire (1P + N + E)
- Input voltage limits - 100...275 V adjustable (for half load)
Output:
- Maximum set power (W) - 4500 W
- Harmonic distortion - Less than 2%
- Output frequency - 50/60 Hz +/- 3 Hz synchronized with the power grid
- Cross factor - 3:1
- UPS type - Dual conversion topology
- Type of voltage form - Sinusoidal signal
- Bypass type - Internal bypass (automatic and manual)
- Maximum set power (VA) - 5000 VA
Accordance:
- Certificates - CE; EAC; IRAM; RCM; VDE
- Marking - CE mark
- Standards - EN/IEC 62040-1:2019/A11:2021; EN/IEC 62040-2:2006/AC:2006; EN/IEC 62040-2:2018
Environmental parameters:
- Ambient operating temperature - 0...40 °C
- Relative humidity - 0...95% without condensation
- Altitude above sea level - 0...10000 ft
- Ambient temperature during storage -15...45 °C
- Relative humidity of storage - 0...95% without condensation
- Storage height 0.00...15240.00 m
- Acoustic level 55 dBA
- Heat dissipation - 931
% - Degree of protection IP - IP20
Batteries and battery life:
- Pre-installed batteries - 0
- Typical recharge time of 1.5 h
- Number of RBC™ cartridges 1
- Battery voltage 192 V
- Charger power (W) - 560 W rated
- Battery capacity in volt-ampere hours - 845 Vach working time
- Battery life 3...5 year(s)
- Spare battery APCRBC140; SR13KXIET; SR16KXIET
- Battery options - SRT192RMBP 1 2535 VACH
SRT192RMBP 2 4225 VACH
SRT192RMBP 3 5915 VACH
SRT192RMBP 4 7605 VACH
SRT192RMBP 5 9295 VACH
SRT192RMBP 6 10985 VACH
SRT192RMBP 8 14365 VACH
SRT192RMBP 10 17745 VACH
- The possibility of increasing the time of autonomy - 1
Communication tools and admin tools:
- Free slots - 1
- Pre-installed SmartSlot&tra boards - Network management card 3 with environmental monitoring
- Alarm - Audible and visible alarms : prioritized by severity
- Emergency Power Off (EPO) - Yes
Surge protection and filtration:
- Rating according to the level of absorbed energy of the vsp - 480 J
