Besplatna dostava APC Smart-UPS SRT 1500VA 230V Prikaži uvećano

APC Smart-UPS SRT 1500VA 230V

SRT1500XLI

Novi proizvod

3 - 5 radnih dana

3 god.

Količina: 1 raspoloživ (kod dobavljača)

Cijena za gotovinu (uplatu na račun):

1 579,88 € s PDV-om

Cijena za kartice:

1 737,87 € s PDV-om

Okvirna cijena po ratama:
12 * 144,82 € s PDV-om
6 * 289,64 € s PDV-om
3 * 579,29 € s PDV-om

Dodaj u listu želja

  • Diners Club International
  • Discover
  • Dinacard
  • WSPay
  • Google Pay

Podaci

Width 8.50 cm
Height 43.20 cm
Depth 50.50 cm
Battery Recharge Time 3 h
Cable Length 1.80 m
Battery Life 3...5 year(s)
Battery type Lead-acid battery
Type of execution Rackmount / Tower
Main Input Voltage 230 V
Main Output Voltage 230 V
Rated power in W 1500 W
Rated power in VA 1500 VA
Product or component type Uninterruptible power supply (UPS)
Input Connection Type IEC 60320 C14
Output Connection Type 6 IEC 60320 C13
Number of cables 1
Provided equipment CD with software, Communication cable, Documentation CD, Installation guide, Removable support feet, USB cable, Warranty card
Battery voltage 48 V
Redundant No
net. Weight 20.50 kg
Mounting preference No preference
Mounting mode Rack-mounted with kit
USB compatible Yes
Network frequency 40...70 Hz auto-sensing
Input voltage limits 100...275 V
Maximum configurable power in VA 1500 VA
Maximum configurable power in W 1500 W
Output frequency 50/60 Hz +/- 3 Hz sync to mains
UPS type On-line
Wave type Sine wave
Product certifications CE
Standards EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018
Ambient air temperature for operation 0..40 °C
Relative humidity 0…95 %
Operating altitude 0...10000 ft
Ambient air temperature for storage -20…50 °C
Storage Relative Humidity 0…95 %
Storage altitude 0.0000000000…15240.0000000000 m
Acoustic level 50 dBA
Alarm Audible and visible alarms : prioritized by severity
Surge energy rate 432 J
Battery charger power 108 W rated
Number of battery replacement quantity 1
Number of battery filled slots 1

Više informacija

Main features
- Working time with 1500W load: 5m 9s
- Output power: 1.5kW / 1.5kVA
- Output connectors:
(6) IEC 320 C13 (Battery backup)
(6) IEC 60320 C13 (Battery backup)
- Rated output voltage: 230V
- Rated input voltage: 230V
- Input connection type: IEC 60320 C14
- Length of the cord: 1.8meters

Exit
- Maximum set power(W): 1.5kW / 1.5kVA
- Distortion of the output voltage shape: Less than 2%
- Output frequency (synchronized with the power grid): 50/60 Hz +/- 3 Hz Synchronized with the power grid
- Other output voltages: 220V, 240V
- Peak load factor: 3:1
- Topology: Topology double conversion
- Type of voltage form: Sinusoidal signal
- Bypass: Built-in bypass

Entrance
- Input frequency: 40 - 70 Hz Auto detection
- Input voltage range during mains operation: 100 - 275V
- Number of power cables: 1
- Other input voltage values: 220 V, 240 V

Batteries and battery life
- Battery Type: Lead acid battery
- Pre-installed batteries: 1
- Typical recharge time: 3 hours
- Rated battery voltage: 48 V
- Replaceable battery: APCRBC155
- Expected battery life (years): 3 - 5
- Charger power (W): 108 Watts
- The possibility of increasing the time of autonomous operation: 1
- Additional equipment to increase battery life: SRT48BP

Communication and administrative tools
- Interface Port(s): RJ-45 Serial, Smart-Slot, USB
- Control panel: Multifunctional monitoring and control console with LCD indicator
- Sound signal: Audio and visual signals with a system of priorities according to severity
- Emergency Power Off (EPO): Yes
- Number of SmartSlot™ interfaces available: 1

Surge protection and noise filtering
- Burst energy rating: 432joules

Physical parameters
- Maximum height: 432MM, 43.2cm
- Maximum width: 85MM, 8.5cm
- Maximum depth: 505MM, 50.5cm
- Net weight: 20.5KG
- Gross weight: 29.6KG
- Dimensions of the transport package: 246x594x749MM
- Color: Black
- Devices on a pallet: 12.0

Environmental Parameters
- Operating temperature: 0 - 40 °C
- Operating range of relative humidity: 0 - 95 (Non-condensing)%
- Operating range of altitude above sea level: 0 - 3048 meters
- Storage temperature: -20 - 50 °C
- Relative humidity of storage: 0 - 95 (Non-condensing) %
- Storage altitude: 0 - 15240 meters
- Acoustic noise level at a distance of 1 m from the surface of the device: 50.0dB(A)
- Online heat dissipation: 317.0BTU/hour
- Protection class: IP20

Accordance
- Compliance with the requirements: CE, EAC
