- Jamstvo: 3 god.
Vaša prava iz zakonskog jamstva
- Odstrani ovaj proizvod iz najdražih proizvoda
- Dodaj ovaj proizvod u najdraže proizvode
- Ispis
Specifikacije
- Width
- 8.50 cm
- Height
- 43.20 cm
- Depth
- 50.50 cm
- Battery Recharge Time
- 3 h
- Cable Length
- 1.80 m
- Battery Life
- 3...5 year(s)
- Battery type
- Lead-acid battery
- Type of execution
- Rackmount / Tower
- Main Input Voltage
- 230 V
- Main Output Voltage
- 230 V
- Rated power in W
- 1000 W
- Rated power in VA
- 1000 VA
- Product or component type
- Uninterruptible power supply (UPS)
- Input Connection Type
- IEC 60320 C14
- Output Connection Type
- 6 IEC 60320 C13
- Number of cables
- 1
- Provided equipment
- CD with software, Communication cable, Documentation CD, Installation guide, Removable support feet, USB cable, Warranty card
- Battery voltage
- 48 V
- Redundant
- No
- net. Weight
- 20.50 kg
- Mounting preference
- No preference
- Mounting mode
- Rack-mounted with kit
- USB compatible
- Yes
- Network frequency
- 40...70 Hz auto-sensing
- Input voltage limits
- 100...275 V 40% load, 176...275 V
- Maximum configurable power in VA
- 1000 VA
- Maximum configurable power in W
- 1000 W
- Output frequency
- 50/60 Hz +/- 3 Hz sync to mains
- Wave type
- Sine wave
- Product certifications
- CE, EAC, UK PSTI
- Standards
- EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018
- Ambient air temperature for operation
- 0..40 °C
- Relative humidity
- 0…95 %
- Operating altitude
- 0...10000 ft
- Ambient air temperature for storage
- -20…50 °C
- Storage Relative Humidity
- 0…95 %
- Storage altitude
- 0.0000000000…15240.0000000000 m
- Acoustic level
- 50 dBA
- Alarm
- Audible and visible alarms : prioritized by severity
- Surge energy rate
- 432 J
- Battery charger power
- 97 W rated
- Number of battery replacement quantity
- 1
- Number of power module free slots
- 0
- Number of battery filled slots
- 1
- Number of battery free slots
- 0
- Fiscalization 2.0 Article
- G46.50.22
- Number of power module filled slots
- 0
Opis
Main features
- Working time with 1000W load: 8m 27s
- Output power: 1.0kW / 1.0kVA
- Output connectors:
(6) IEC 60320 C13 (Battery backup)
(6) IEC 320 C13 (Battery backup)
- Rated output voltage: 230V
- Rated input voltage: 230V
- Input connection type: IEC 60320 C14
- Length of the cord: 1.8meters
Exit
- Maximum set power (W): 1.0kW / 1.0kVA
- Distortion of the output voltage shape: Less than 2%
- Output frequency (synchronized with the power grid): 50/60 Hz +/- 3 Hz Synchronized with the power grid
- Other output voltages: 220V, 240V
- Peak load factor: 3:1
- Topology: Topology double conversion
- Type of voltage form: Sinusoidal signal
- Bypass: Built-in bypass
Entrance
- Input frequency: 40 - 70 Hz Auto detection
- Input voltage range during mains operation: 50 - 150 40% load, 80–150V
- Number of power cables: 1
- Other input voltage values: 220 V, 240 V
Batteries and battery life
- Battery Type: Lead acid battery
- Pre-installed batteries: 1
- Typical recharge time: 3 hours
- Rated battery voltage: 48 V
- Replaceable battery: APCRBC155
- Expected battery life (years): 3 - 5
- RBC™ quantity: 1
- Charger power (W): 97 Watts
- The possibility of increasing the time of autonomous operation: 1
- Additional equipment to increase battery life: SRT48BP
Communication and administrative tools
- Interface Port(s): RJ-45 Serial, Smart-Slot, USB
- Control panel: Multifunctional monitoring and control console with LCD indicator
- Sound signal: Audio and visual signals with a system of priorities according to severity
- Emergency Power Off (EPO): Yes
- Number of SmartSlot™ interfaces available: 1
Surge protection and noise filtering
- Burst energy rating: 432joules
Physical parameters
- Maximum height: 432MM, 43.2cm
- Maximum width: 85MM, 8.5cm
- Maximum depth: 505MM, 50.5cm
- Net weight: 20.5KG
- Gross weight: 29.6KG
- Dimensions of the transport package: 246x594x749MM
- Color: Black
- Devices on a pallet: 12.0
Environmental Parameters
- Operating temperature: 0 - 40 °C
- Operating range of relative humidity: 0 - 95 (Non-condensing)%
- Operating range of altitude above sea level: 0 - 3048 meters
- Storage temperature: -20 - 50 °C
- Relative humidity of storage: 0 - 95 (Non-condensing) %
- Storage altitude: 0 - 15240 meters
- Acoustic noise level at a distance of 1 m from the surface of the device: 50.0dB(A)
- Operational heat dissipation: 317.0BTU/hour
- Protection class: IP20
Accordance
- Compliance with the requirements: CE, EAC
- Working time with 1000W load: 8m 27s
- Output power: 1.0kW / 1.0kVA
- Output connectors:
(6) IEC 60320 C13 (Battery backup)
(6) IEC 320 C13 (Battery backup)
- Rated output voltage: 230V
- Rated input voltage: 230V
- Input connection type: IEC 60320 C14
- Length of the cord: 1.8meters
Exit
- Maximum set power (W): 1.0kW / 1.0kVA
- Distortion of the output voltage shape: Less than 2%
- Output frequency (synchronized with the power grid): 50/60 Hz +/- 3 Hz Synchronized with the power grid
- Other output voltages: 220V, 240V
- Peak load factor: 3:1
- Topology: Topology double conversion
- Type of voltage form: Sinusoidal signal
- Bypass: Built-in bypass
Entrance
- Input frequency: 40 - 70 Hz Auto detection
- Input voltage range during mains operation: 50 - 150 40% load, 80–150V
- Number of power cables: 1
- Other input voltage values: 220 V, 240 V
Batteries and battery life
- Battery Type: Lead acid battery
- Pre-installed batteries: 1
- Typical recharge time: 3 hours
- Rated battery voltage: 48 V
- Replaceable battery: APCRBC155
- Expected battery life (years): 3 - 5
- RBC™ quantity: 1
- Charger power (W): 97 Watts
- The possibility of increasing the time of autonomous operation: 1
- Additional equipment to increase battery life: SRT48BP
Communication and administrative tools
- Interface Port(s): RJ-45 Serial, Smart-Slot, USB
- Control panel: Multifunctional monitoring and control console with LCD indicator
- Sound signal: Audio and visual signals with a system of priorities according to severity
- Emergency Power Off (EPO): Yes
- Number of SmartSlot™ interfaces available: 1
Surge protection and noise filtering
- Burst energy rating: 432joules
Physical parameters
- Maximum height: 432MM, 43.2cm
- Maximum width: 85MM, 8.5cm
- Maximum depth: 505MM, 50.5cm
- Net weight: 20.5KG
- Gross weight: 29.6KG
- Dimensions of the transport package: 246x594x749MM
- Color: Black
- Devices on a pallet: 12.0
Environmental Parameters
- Operating temperature: 0 - 40 °C
- Operating range of relative humidity: 0 - 95 (Non-condensing)%
- Operating range of altitude above sea level: 0 - 3048 meters
- Storage temperature: -20 - 50 °C
- Relative humidity of storage: 0 - 95 (Non-condensing) %
- Storage altitude: 0 - 15240 meters
- Acoustic noise level at a distance of 1 m from the surface of the device: 50.0dB(A)
- Operational heat dissipation: 317.0BTU/hour
- Protection class: IP20
Accordance
- Compliance with the requirements: CE, EAC
