Specifikacije
- Width
- 10.10 cm
- Height
- 14.20 cm
- Depth
- 27.90 cm
- Battery type
- Lead acid, sealed, maintenance free
- Type of execution
- Tower
- Main Input Voltage
- 230 V
- Main Output Voltage
- 230 V
- Rated power in W
- 840 W
- Rated power in VA
- 1200 VA
- Input Connection Type
- Schuko
- Output Connection Type
- 2 Schuko
- net. Weight
- 4.50 kg
- Network frequency
- 50/60 Hz (automatic selection)
- Input voltage limits
- +20%/-25%
- Maximum configurable power in VA
- 1200 VA
- Maximum configurable power in W
- 840 W
- Output frequency
- 50/60 Hz (automatic selection)
- Wave type
- Modified sinewave
- Transfer time
- 2 ms typical
- Standards
- IEC 62040-1-1, IEC 62040-2, IEC 62040-3
- Ambient air temperature for operation
- 0..55 °C
- Relative humidity
- 0…95 %
- Operating altitude
- 0...3000 m
- Acoustic level
- 40 dBA
- Colour
- Black
- IP protection
- IP20
- Backup time
- 10-40 min
- Input Frequency Range
- +/- 5%
- Fiscalization 2.0 Article
- G46.50.22
Opis
Maximum computer power*
1200 VA/840 W
Technologies
Line Interactive with stabilizer
Interface
USB port
Cooling
Natural
Audible noise
< 40 dBA at a distance of 1 m
Dimensions (UPS) WxHxD
10.1x14.2x27.9 cm
Dimensions (with packaging) WxHxD
18x22x34 cm
Weight
4.5 kg
Number of phases
1F+N
The rated voltage is single-phase
230 V AC
Input voltage range
+20%/-25%
Rated frequency
50/60 Hz (automatic selection)
Input frequency range
+/- 5%
Number of phases
1F+N
Rated voltage Single-phase
230 V AC
Voltage regulation (Line mode)
AVR (Automatic voltage regulation)
Voltage regulation (battery mode)
+/- 5%
Frequency
50/60 Hz (automatic selection)
The signal form of the inverter
Modified sine wave
The possibility of overload
< 130 %
Transfer time
2 ms (typical)
Lead-acid type, sealed, maintenance-free
Backup time (typical)
10-40 min.
Operating temperature
From 0 to 55 °C (recommended from 20 to 25 °C)
Humidity
< 95% non-condensing
Maximum height
3000 m
IP protection
IP20
